Application
When a home electric refrigerator and a freezer electricity warehouse are examined, Household Refrigerating Appliances Test Room can adjust the surrounding temperature humidity of the tested refrigerator based on the standard of ISO15502 and IEC62552. Moreover, the consumption electric power amount test of two or more refrigerators can be done at the same time.
Test Item
Cooling Speed Test, Storage Temperature Test, Energy Consumption Test, Ice-making Capacity Test, Defrosting Test, Temperature Rise of Load Time, Freezing Capacity Test, Dew Test
Technical Specifications
| Parameter | Specification |
|---|---|
| Tested Type | Refrigerator, freezer and household refrigerator-freezer |
| Dry-bulb Temperature Range | -5 ～ 50 °C |
| Temperature Control Accuracy | ±0.3 °C |
| Relative Humidity Range | 45 ～ 85% RH |
| Humidity Control Accuracy | ±3% RH |
| Temperature Uniformity (No Load) | ±0.5 °C |
| Control Modes | Manual and Auto Mode |
| Working Stations | Up to 12 |
